UPS Power HAT for Raspberry Pi Zero
Skip to product information
UPS Power HAT for Raspberry Pi Zero
- Cascading (from bottom) design saves space while powering raspberry pi and expansion boards without affecting GPIO expansion.
- Support up to 400mA charging current for battery charging
- Can be charged and supplied power to raspberry pi at the same time.
- With 3 LED power indicator FULL indicator ,CHARGE indicator and 5V Output Indicator.
- The HAT comes with a Lithium Polymer (LiPo) with capacity of 1000mAh.
- Able to power Raspberry Pi Zero W for around 30 minutes without main supply under normal usage.
- Removable battery, user can choose a more larger capacity lithium battery pack (NOTE: typical voltage must be 3.7V).
- With safety protection circuit to prevent overcharge and over-discharge.
- Support I2C communication with Raspberry Pi main board for battery voltage and capacity
